Simple, Stiff, and Superfast

The Boss line, which accounts for more than 30,000 working units over the world, has been further improved to redefine the market standard once again. The BOSS 552 HD is an automatic bar feeder for bars with diameters between 5 and 51 mm, ideal for working with fixed headstock and sliding headstock lathes, available for bar lengths from 700 to 6,380 mm. It guarantees the maximum reliability without any compromises; the continuous improvement made to this product, the attention to detail, and more than 20 years of history have allowed the Boss line to set the market standard of quality in every working application.

Characteristics

  • Round bars 5 – 51 mm
  • Bar length 700 – 6,380 mm
  • MP Magazine available Yes, 280 mm + magazine extension 180 mm
  • F Magazine available Yes, 1.2 tons (for bar length of 3200 mm)
  • Bar changeover time 19 sec. (for bar length of 3200 mm)
  • Hexagonal bars 5 – 43 mm
  • Fixed headstock Yes
  • UP Magazine available No
  • OAB Magazine available Yes, 1.2 tons (for bar length of 3200 mm)
  • Square bars 5 – 36 mm
  • Mobile headstock Yes
  • P Magazine available Yes, 1,800 mm
  • Remnant length L = 21: 295 mm; L = 32, 37, 44, 64: 400 mm (optional 700 mm)

Specifications

  • Bar weight Max 55 kg
  • Reversible magazines Yes
  • Compressed air 8 bar
  • Bar feeder weight Ver.21 – 650 kg Ver.32 – 885 kg Ver.37 – 950 kg Ver.44 – 1030 kg
  • Feed rate 750 mm/sec. (adjustable)
  • Installed power 2 kW
  • Number of spindles 1
  • Return speed 1200 mm/sec. (adjustable)
  • Operating Voltage 230/400 V
